Franklin Electric 1 1/2 HP 7GPM Stainless Steel 3200 Series Submersible Well Pump

**FPS 3200 Series Submersible Pump**

The 3200 Series submersible pumps are expertly crafted with all components, including the cable guard, fitting within the diameter of Franklin Electric's top-performing 4-inch submersible motor. This compact pump end design is perfect for installations in wells that are narrow or encrusted, as opposed to standard 4-inch wells. Additionally, the 3200 Series features a hydraulic stage configuration that maximizes water flow and pressure output for deeper well installations.

**Key Features:**

- Smaller pump diameter than a typical 4-inch submersible allows for easier installation in narrower 4-inch wells.
- Hex rubber bearing and ceramic shaft sleeve enable sand and abrasives to flow through, significantly reducing shaft wear and minimizing upper bearing failures.
- Enhanced hydraulic performance is achieved for deeper installations, regardless of horsepower and flow ratings.
- The floating stage design optimizes efficiency while decreasing the downthrust load on the motor.
- Modified PPO diffuser and disc, reinforced with 300 Series stainless steel thrust and eye seals, provide durability and abrasion resistance.
- Acetal impeller ensures high performance, boosting pressure output while limiting friction-related losses.
- Includes a removable spring-loaded check valve.
- Features a stainless steel pump intake screen and stainless steel cable guard.
- Maximum allowable water temperature: 120 °F / 49 °C.
- Driven by a corrosion-resistant Franklin Electric 4-inch submersible motor with lightning protection.

Shipping Information:

Most orders ship within 24-48 hours, with eligible orders of in-stock items received by 12pm ET processing and shipping the same day.
Shipping weight: 28lbs
Shipping Dimensions: 27x17x10

Franklin Electric 7FR15S4-2W230 Submersible Pump Specifications

Water Well Motors

• BODY CONSTRUCTION: 304 Stainless Steel
• HORSEPOWER: 1.5 HP
• VOLTAGE: 1ø, 230V
• RPM: 3450
• MAX AMBIENT TEMPERATURE: 120°F/49°C
• LEAD: 2-wire

Water Well Pump Ends

• DISCHARGE SIZE: 1.25” FNPT
• NOMINAL FLOW RATING: 7 GPM
• HORSEPOWER: 1.5 HP
• MAXIMUM CAPACITY: 11 GPM
• MAXIMUM HEAD: 590’
• STAGES: 23
• IMPELLER DESIGN: Floating Stack
• IMPELLER MATERIAL: Acetal
• BODY MATERIAL: Stainless Steel
• MAXIMUM LIQUID TEMPERATURE: 120°F/49°C
